Machine Stretch Film
Machine stretch film is an essential packaging material widely used in the logistics, shipping supply, manufacturing, construction, retail, automotive, distribution centers, etc., for securing palletized loads during transit and storage. These films provide superior load containment, stability, and protection.
Made from high-performance polyethylene resins, machine stretch films deliver consistent stretchability and strength, enabling users to achieve optimal load security with minimal material usage. Additionally, they offer excellent tear resistance, making them suitable for securing sharp or irregularly shaped products. With its uniform thickness and stretching performance, these films ensure even tension distribution across the load, minimizing the risk of damage during transport.
These films are engineered with advanced properties such as puncture resistance, high clarity for easy product identification, excellent cling to prevent slippage, UV protection and recyclable and biodegradable options to promote sustainability without compromising performance.
Specification Table of Machine Stretch Film Wraps
|
Material Composition
|
Linear low-density polyethylene (LLDPE)
Co-extruded films with multiple layers for strength and flexibility
|
|
Thickness Range
|
10 to 80 gauge (1 to 20 microns)
Common: 50–80 gauge for medium-duty applications
|
|
Width Options
|
Standard: 20", 30", or 40" rolls
Custom widths available for specialized applications
|
|
Roll Length
|
Light rolls: ~1,500 ft
Heavy rolls: 5,000 - 10,000 ft
|
|
Film Types
|
Blown Stretch Film: High puncture resistance, noisy application
Cast Stretch Film: Smooth application, clearer, quieter
|
|
Stretchability
|
Pre-stretch levels: 150% - 300% (1 foot of film can stretch up to 4 feet)
High-performance films may offer up to 400% stretch
|
|
Load Holding Force
|
Standard: 5 - 20 lbs per inch
Heavy-duty: 20 - 30 lbs per inch
|
|
Cling Properties
|
One-sided or double-sided cling for optimal adhesion without sticking to adjacent pallets
|
|
Transparency
|
Clear/Transparent, Opaque (Black or White)
|
|
Puncture Resistance
|
High puncture resistance to withstand sharp edges and rough handling
|
|
Tensile Strength
|
Ranges from 2,500 - 4,000 psi, depending on the grade of film
|
|
Environmental Features
|
100% Recyclable- Some films include recycled content for sustainability
|
|
Core Options
|
Standard cores: 3" diameter
Extended cores available for easier machine handling
|
|
Film Layers
|
Mono-layer Or Multi-layer films/p>
|
|
UV Resistance
|
UV-inhibited films
|
|
Temperature Range
|
Usable from -20°F to 150°F (-29°C to 65°C)
|
|
Machine Compatibility
|
Compatible with semi-automatic and fully automatic stretch wrapping machines
|
|
Common Roll Weights
|
Light: ~25 lbs per roll
Heavy-duty: 50 to 75 lbs per roll
|
Available in a variety of gauges (10 to 90 Gauge), widths (20 to 40 Inches), and roll lengths (1500 to 10000 ft) , machine stretch films cater to diverse load sizes and weights, ensuring compatibility with a wide range of stretch wrap equipment, including rotary arm, turntable, and orbital machines. Widely used in logistics and warehousing industries to secure the pallets for internal storage or transportation, to stabilize loads during long-haul shipping. Below is the quick selection guide that gives high level recommendations based on application and your business requirements.
Film Selection Guide
|
Application
|
Recommended Film
|
|
Lightweight, uniform loads
|
50–60 gauge, standard cast film
|
|
Medium-weight or irregular loads
|
70–80 gauge, high-performance blown film
|
|
Heavy-duty industrial loads
|
90+ gauge, multi-layer reinforced film
|
|
Outdoor storage or UV exposure
|
Opaque, UV-resistant stretch film
|
|
High-security applications
|
Black opaque film
|
